Description
IONVOLT TW4000-Pro 5.12kWh Powerwall Lithium Ion Battery
IONVOLT TW4000-Pro-LT51.2v 100Ah
Battery System Specifications
- Rated voltage: 51.2V
- Rated capacity: 100AH
- Battery: LF100/5060118 3.2V100AH
- Combination mode: 16S1P
- Mounting type: Wall mount
- continuous charge current: 100A
- continuous discharge current:100A
- Peak discharge current/time: 150A/1s
- Battery Module Weight: 48.5kg
- Dimension (LxWxD): 490x490x168.5mm
Features
The IONVOLT TW4000PRO lithium iron phosphate battery storage system provides an energy storage functionality for photovoltaic power generation users through single or parallel combination. During the day, the excess power for a solar energy system can be stored in the battery, and at night or when needed, the stored energy is used to power electrical equipment, which can improve the efficiency of solar system through peak shaving, and provision of emergency backup power.
The TW4000PRO battery pack uses lithium iron phosphate as the battery anode material and is equipped with a high-performance BMS to effectively manage the battery cells. The system has the following characteristics:
- Meets European ROHS regulations, pass SGS certification, use the best non-toxic and pollution-free battery;
- The battery anode is made of lithium iron phosphate (LiFePO4) material, which has good safety performance and long cycle life;
- Adopts high-performance BMS battery management mode, with over-discharge, over-charge, over-current, temperature and other protection functions;
- With charge and discharge automatic management and single cell balance function;
- Fully intelligent design, equipped with a centralized monitoring module, with three remote (telemetry, remote signaling and remote control) functions;
- Flexible configuration, multiple system units connected in parallel can extend the power supply time of the system;
- Self-cooling method, the whole system has extremely low noise;
- The battery has less self-discharge, and it can be recharged for up to 10 months during storage; no memory effect, shallow charging and discharging;
- Wide temperature working range, -20 ℃ ~ + 55 ℃, good cycle life and discharge performance at normal temperature;
- Small battery size and light weight.
